PE Elbow 90°

High-quality PE100 elbow fitting for water supply systems. Superior durability and easy installation with butt fusion connection.

PE Elbow 90°
View 1 View 1 View 1 View 1 View 1

PE Elbow 90°

Hot Product

UPVC pipes & fittings are used for the high-pressure water distribution system and are an ideal replacement for galvanised iron pipe system for all cold water applications.

  • 1.Delivery: 10-30 days depending on the total quantity.
  • 2.Packing: 3/6/9/12m/ Pcs for straight, with plain ends, RRJ end or SCJ end.
  • 3.CO (Certificate of Origin): China, CO could be provided by free.
  • 4.Products Inspection: Raw material, production process, delivery or third-party factory inspection
  • 5.MOQ: Trial Order or 1*20ft containers by mixed loading.

Request Quote Download Specs

Need help? Contact our technical support team

+86 1551559 6408
Property Value Standard
Material Grade PE100 (PE4710) ISO 4427
Density 0.949-0.955 g/cm³ ISO 1183
Tensile Strength at Yield 25 MPa ISO 527
Elongation at Break 600% ISO 527
Impact Strength (23°C) 25 kJ/m² ISO 179
Vicat Softening Temperature 123°C ISO 306
Operating Temperature Range -40°C to +60°C ISO 4427
Key Features & Benefits
  • Superior corrosion resistance for long service life
  • High impact strength and flexibility
  • Smooth inner surface reduces friction loss
  • Easy installation with butt fusion welding
  • NSF certified for potable water applications
  • 50+ year design life expectancy
Recommended Applications
Water Supply Systems
  • Potable water distribution
  • Municipal water networks
  • Building water supply
  • Irrigation systems
Industrial Applications
  • Chemical processing plants
  • Food and beverage industry
  • Pharmaceutical facilities
  • Manufacturing plants
Environmental Systems
  • Wastewater treatment
  • Storm water management
  • Landfill leachate collection
  • Geothermal systems
Specialized Uses
  • Mining operations
  • Marine applications
  • Agricultural irrigation
  • Fire protection systems
Downloadable Resources
Technical Datasheet

Complete technical specifications and performance data

Download PDF
Installation Guide

Step-by-step installation procedures and best practices

Download PDF
Certification Documents

ISO, NSF, and other certification certificates

Download PDF
CAD Drawings

2D and 3D CAD files for engineering design

Download ZIP
