Key Features
- Two sockets + one spigot: main ends are rubber ring sockets; branch is spigot.
- Rubber ring seal: quick main pipe connection.
- Spigot branch: can insert into another fitting's rubber ring socket for line extension.
- Flexible connection: accommodates minor pipe movement.
Manufacturing Process
Multi-slide precision injection molding. Main sockets have rubber ring grooves; branch spigot is chamfered per standards. Reinforced junction design.
Critical Process Parameters
- Main socket rubber ring groove accuracy.
- Precise branch spigot OD and chamfer machining.
- Coaxiality and perpendicularity control of all ports.
Raw Material Characteristics
- Material Composition: UPVC, EPDM sealing rings.
- Material Properties: Consistent with series.
Typical Applications
- Nodes requiring branch with continued extension in rubber ring systems.
- Tee branch connections on main pipelines.
Application Scenarios
- Branch and extension nodes in rubber ring piping systems.
