| 规格 (Specifications) |
|---|
| S20×1/2M |
| S20×3/4M |
| S25×1/2M |
| S25×3/4M |
| S25×1M |
| S32×1/2M |
| S32×3/4M |
| S32×1M |
| S40×1%M |
| S50×1%M |
| S63×2M |
| S75×2%M |
| S90×3M |
| S110×4M |
Key Features
- Embedded electrofusion coils for precision welding
- Metric/BSP male thread configuration options
- Automated fusion parameter monitoring system
- Smooth bore design without flow obstruction
Typical Applications
- Valve connections in water treatment plants
- HDPE-metal transitions in building water supply
- Irrigation pump station equipment interfaces
- Industrial cooling water circulation systems
Manufacturing Process
Precision injection molding with pre-embedded resistance wire
- Melt temperature control (200±5℃)
- Coil positioning accuracy (±0.1mm)
- Cooling gradient control (<15℃/min)
- Thread coaxiality tolerance (ISO 228-1)
Raw Material Characteristics
- Density: ≥948 kg/m³ (ISO 1183)
- Melt Flow Index: 0.35g/10min (190℃/5kg)
- Elastic modulus: 1100 MPa
- ESCR: F0>1000h
- Metering device installations in potable water networks
- Pump house interfaces in fire water supply systems
- Pretreatment unit connections in desalination plants
- Equipment connections in mine dewatering systems
